DHLC800-500P Electric Lift Table Legs 1V2 Hall

Model:

500P

Color:

Black
Grey
White

Quantity:

Add to Inquiry

About this item

1. DHLC800 Electric Lifting Table Legs: For versatile applications

2. Max Load 80kg: Supports up to 80kg load capacity

3. Speed 25MM/S: Moves at 25MM/S speed

4. Hall Sensor & Infinite Switch: Equipped with Hall sensor and infinite switch

5. 2/4 Columns, Multiple Strokes: Choose from 2 or 4 columns, with 500MM/650MM/900MM stroke options. Suitable for various settings like furniture desks, industrial lift tables, photography tables, labs, and TV lifts.

Product Description

PRODUCT DESCRIPTION

DHLC800 electric lifting table legs, maximum load 80kg, speed 32MM/S, built-in Hall sensor, infinite switch, need to be controlled by Hall controller. The electric lifting column is divided into 2 columns and 4 columns, and the stroke is divided into 500MM/650MM/900MM.
Suitable for furniture desks, industrial lift tables, photography tables, laboratory lift tables, TV lifts and other places.

TECHNICAL PARAMETERS

Model	500P
Initial Height	650MM
Final Height	1150MM
Stroke Length	500MM
Section	2
Input Voltage	DC24V~DC30V
Load Pull Capacity(N)	1200N
Load Push Capacity(N)	1200N
Self-locking Capacity(N)	1200N
Maximum Power	55W
Maximum Speed	25MM/S
Color	RAL9005(Black)
Usage Frequency	10% Work System, Maximum 1 Hour Continue Working
Ambient Temperature	-10℃ ~ +60℃
Optional Features	Hall Sensor
Limit Switches	None
Install Screws	M6*16MM, If the screw is too long, it will damage the motor
Rated Working Capacity	80% of Maximum Load, Unable to maintain maximum load operation for a long time
Note	2 columns lifting system and 4 columns lifting system, any columns cannot exceed 100KG load and needs to be kept fixed.
