1. Low-Noise Performance: Equipped with a 30dB low-noise plastic motor gear, the DHLA4000 ensures quiet and unobtrusive operation while maintaining exceptional performance.
2. Impressive Load Capacity: With a maximum load capability of 4000N, this electric linear actuator offers robust power to handle a wide range of tasks effectively.
3. Swift Movement: Achieve a maximum speed of 26MM/S, allowing for efficient and rapid linear motion suited for various applications.
4. Versatile Application: Ideal for medical, furniture, and industrial sectors, the DHLA4000 adapts seamlessly to different fields, meeting diverse needs.
5. Wide Automation Compatibility: Suitable for integration into automatic control systems, this actuator finds utility in windows of construction vehicles, cleaning vehicles, ships, and cargo holds, enhancing automation and convenience.
DHLA4000 electric linear actuator uses 30dB low-noise plastic motor gear, maximum load can reach 4000N, maximum speed 20MM/S.
Suitable for medical, furniture, industrial and other fields.It can be installed in the automatic control system of Windows such as construction vehicles, cleaning vehicles, ships and cargo holds.
| Voltage | DC12V | |||
| No-load Speed (MM/S) | 5 | 10 | 15 | 20 |
| Load Pull Capacity(N) | 4000 | 2000 | 1300 | 800 |
| Load Push Capacity(N) | 4000 | 2000 | 1300 | 800 |
| Self-locking Capacity(N) | 4000 | 2000 | 1300 | 800 |
| Stroke Length | 50-1000MM (≥800MM Stroke Max Load 2000N) | |||
| Noise | 30dB | |||
| Motor Power | 72W | |||
| Limit Switches | Built-in | |||
| Operating Frequency | 10% max 60min. continuous use | |||
| Operating Temperature | 0°C~+40°C | |||
| IP Grade | IP43 | |||
| Inner Tube | Aluminum Tube | |||
| Lead Screw Type | Type T | |||
| Mechanical Life | More than 300,00 times | |||
